Proportional directional valves

BOSCH REXROTH
TAICIN PUMP-VALVES

Proportional directional valve, pilot-operated, with integrated electronics (OBE)

2WFCE

Size 16, 25, 32, 40, 50 Component series 1X Maximum operating pressure 420 bar Maximum flow 1500 l/min

Proportional directional valves, pilot operated, with integral electronics (OBE) and electrical position feedback

4WRKE

Size 10, 16, 25, 27, 32, 35 Component series 3X Maximum operating pressure 350 bar Maximum flow 3000 l/min

4/2 and 4/3 proportional directional valves, pilot-operated, without electrical position feedback, without integrated electronics (OBE), with spool position indicator

4WRZEM

Size 10, 16, 25 Component series 1X Maximum operating pressure 350 bar Maximum flow 870 l/min

4/2 and 4/3 proportional directional valves, pilot-operated, without electrical position feedback, with external electronics, with spool position indicator

4WRZM

Size 10, 16, 25 Component series 1X Maximum operating pressure 350 bar Maximum flow 870 l/min

4/2 and 4/3 proportional directional valves, pilot operated, without electrical position feedback, with spool position display

4WRHM

Size 10, 16, 25 Component series 1X Maximum operating pressure 350 bar Maximum flow 870 l/min

5/2 and 5/3 proportional directional valves, pilot-operated, without electrical position feedback, without integrated electronics (OBE)

5WRH

Size 52 Component series 7X Maximum operating pressure 350 bar Maximum flow 2800 l/min

5/2 and 5/3 proportional directional valves, pilot-operated, without electrical position feedback, with integrated electronics (OBE)

5WRZE

Size 52 Component series 7X Maximum operating pressure 350 bar Maximum flow 2800 l/min

5/2 and 5/3 proportional directional valves, pilot-operated, without electrical position feedback, without integrated electronics (OBE)

5WRZ

Size 52 Component series 7X Maximum operating pressure 350 bar Maximum flow 2800 l/min

4/3 proportional directional valve, pilot-operated, without electrical position feedback, without integrated electronics (OBE)

4WRH

Size 10, 16, 25, 32, 52 Component series 7X Maximum operating pressure 350 bar Maximum flow 2800 l/min

Proportional directional valves, pilot operated, without electrical position feedback

4WRZ ...XE

Size 10, 16, 25, 32 Component series 7X Maximum operating pressure 350 bar Maximum flow 1600 l/min Area of application in accordance with the Explosion Protection Directive 2014/34/EU: II 2G Type of protection of the valve solenoids: Ex eb mb IIC T4 Gb according to EN 60079-7 / EN 60079-18

Proportional directional valves, pilot operated, without electrical position feedback, with integrated electronics (OBE)

4WRZE

Size 10, 16, 25, 32, 52 Component series 7X Maximum operating pressure 350 bar Maximum flow 2800 l/min

Proportional directional valves, pilot operated, without electrical position feedback, without integrated electronics (OBE)

4WRZ

Size 10, 16, 25, 32, 52 Component series 7X Maximum operating pressure 350 bar Maximum flow 2800 l/min

2/2 proportional directional valves, direct operated (High Performance)

KKDSR2

Size 2 Component series A Maximum operating pressure 350 bar Maximum flow 58 l/min

2/2 proportional directional valves, direct operated (High Performance)

KKDSR1

Size 1 Component series B Maximum operating pressure 350 bar Maximum flow 38 l/min

Proportional directional valves, direct operated, with pQ functionality

STW 0195, STW 0196

Size 6, 10 Component series 2X, 1X

4/3 proportional directional valves, direct operated, with pQ functionality

4WREQ

Size 6, 10 Component series 2X Maximum operating pressure 315 bar Maximum flow 180 l/min

4/3 proportional directional valves with integrated digital electronics and field bus interface (IFB-P)

4WREF

Size 6, 10 Component series 2X Maximum operating pressure 315 bar Maximum flow 180 l/min

4/3 proportional directional valves, direct operated, with integrated electronics (OBE)

4WREEM

Size 6, 10 Component series 2X Maximum operating pressure 315 bar Maximum flow 180 l/min

4/2 and 4/3 proportional directional valves, direct operated, wit electrical position feedback, with integrated electronics (OBE)

4WREE

Size 6, 10 Component series 2X Maximum operating pressure 315 bar Maximum flow 180 l/min

4/2 and 4/3 proportional directional valves, direct operated, wit electrical position feedback, without integrated electronics (OBE)

4WRE

Size 6 Component series 2X Maximum operating pressure 315 bar Maximum flow 80 l/min

Proportional directional valve, direct operated, without electrical position feedback

4WRA ...XE

Size 6 Component series 2X Maximum operating pressure 315 bar Maximum flow 22 l/min Area of application in accordance with the Explosion Protection Directive 2014/34/EU: II 2G Type of protection of the valve solenoids: Ex eb mb IIC T4 Gb according to EN 60079-7 / EN 60079-18

4/2 and 4/3 proportional directional valves, direct operated, without electrical position feedback, with integrated electronics (OBE)

4WRAE

Size 6, 10 Component series 2X Maximum operating pressure 315 bar Maximum flow 75 l/min

4/2 and 4/3-Way Proportional Directional Control Valve Direct Operated

4WRA(E)B6

Size 6 Component series 1X Maximum operating pressure 350 bar Maximum flow 30 l/min

4/2 and 4/3 proportional directional valves, direct operated, without electrical position feedback, without integrated electronics (OBE)

4WRA

Size 6, 10 Component series 2X Maximum operating pressure 315 bar Maximum flow 75 l/min
